XAS 110 Air Compressor

$17,865.00

Weight: 1100 lbs

Add to Cart:

Atlas Copco XAS 110 Air Compressor

Fixed shipping to lower 48 states - $750

The XAS 110 is Atlas Copco's latest model and is the result of over a decade of continuous development. This compressor is perfect for single tool applications (or two if the new RTEX breaker is used) and for sites with difficult access and terrain. This model is part of Atlas Copco's legendary 8 Series range. The models in the 8 Series have three key things in common:

Lightweight: Always below 1650 Lbs. A footprint at least 10% more compact than any other option.

Service: Simplicity, speed and long service intervals.

Built better: More features as standard. Breaking new ground when it comes to efficiency (at least 12% improved).

The result is a compressor which can produce 110 CFM without the need for any exhaust after treatment. The 8 Series ticks all the boxes when it comes to delivering outstanding performance in all of these categories.

Technical data

Compressor XAS 110
Actual free air delivery (FAD) cfm 110
Normal effective working pressure psi 100
Max. sound pressure level @ 23’ (7m) at normal working speed & pressure dB(a) 70
Air receiver capacity US Gal (L) 2.34 (10)
Compressor oil capacity US Gal (L) 1.98 (7.5)
Air compressor outlets   2 x 34"
Engine
Engine model   Kubota D 902 T4F
Emissions regulation US EPA Tier 4 Final
Number of cylinders   3
Engine speed (Unloaded) rpm 200
Engine speed (Maximum loaded) rpm 3600
Engine oil capacity US Gal (L) 0.95 (3.6)
Fuel tank capacity US Gal (L) 7.35 (27.82)
Fuel consumption at 100% load Gal/Hr (L/Hr) 1.32 (4.98)
Dimensions and weight (including undercarriage)
Weight (inc. fuel) lb 1100
Length in 79
Width in 48
Height in 51




  • Model: AC-8162061090
